We understand that custom tank requirements are not the same. In addition to building CS and SS pressure vessels to meet your needs and requirements, our team of engineers, quality control, and customer focused support personnel can help you by designing and delivering cost effective solutions. To receive a quote on a custom pressure vessel, please fill out the custom tank specification sheet below and send to us at tankinfo@www.johnwood.com, or give us a call to discuss your needs and requirements.
Certifications
- ASME Section VIII, Division 1
- Pressure Equipment Directive (PED) 97/23/EC
- Canadian Registration (CRN)
- American Bureau of Shipping (ABS)
- US Coast Guard (USCG)
- American Water Works Association (AWWA)
Fabrication Capabilities
- Custom tanks up to 120″ in diameter and 30′ in length
- Carbon Steel, 304 & 316 Stainless Steel
- Wall thicknesses up to 1-1/2″
- Interior Linings and Exterior Painting
Testing Capabilities
- Hydrostatic pressure testing up to 8,800 PSI
- Pneumatic pressure testing
- Readiography Testing (RT)
- Positive material identification (PMI)
- Burnell hardness readings
- Liquid dye penetrant (PT)
- Ultrasonic inspection (UT)
- Magnetic particle inspection (MT)
- Production weld coupon testing
- Post Weld Heat Treatment
- Weld map tracking
Custom Tank Specification Sheet
